Copper Nickel 95/5 Pipe

Home
Copper Nickel 95/5 Pipe

Welded Pipes

Seamless Pipes

Specification

Standards	ASTM, AISI, JIS, DIN, EN, SUS, GB
Types	Welded, Seamless, ERW, Fabricated, CEW, CDW, CDS, DOM
Size range	8" NB to 24" NB
Production technique	Decoiling, Punching, Bending, Welding, Cutting, Moulding
Form	Round, Hydraulic, Coiled, Square, U Shape, Rectangular, Straight, Honed Tubes, Pan Cake Coils
Thickness Range	SCH 10, SCH 160, SCH XXH, SCH XXS, SCH 5, SCH 40, SCH XS, SCH 80S, SCH 80
Custom Size/Thickness	Available
End	Treaded, Beveled End, Plain End
Surface Finish	8K, 1D, No.3, 180G, BA, No.4, 500G, No.1, Mirror Polished, 320G, HL, No.8, 400G, 2B, 600G or 800G Mirror finish Tubing, 2D, 400G Satin/ Hairline or Custom Finish as per customer's specification.
Marking Standard	Name of Manufacturer
	Schedule
	Pressure Class
	Tube Size, etc
Test Certificates	Third Party Inspection Report
	Manufacturer Test Certificate
	Raw Materials Certificate
	100% Radiography Test Report
	Laboratory Test Certificate from Govt. Approved Lab
	EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)

Cupro Nickel 95/5 U Bend Tubes Equivalent Grades

STANDARD	UNS	WERKSTOFF NR.
Cu-Ni 95/5	C70400	-

Cu-Ni 95/5 Condenser U Shaped Heat Exchanger Tubes Chemical Composition

Element	Cu-Ni 95/5
Sn	0.10 Max
Pb	0.05 Max
Ni	4.00 - 5.00
Fe	0.10 Max
Mn	0.25 Max.
As	0.10 Max.
Cu Ag	95.00 - 96.000
Sb	0.01 Max
Bi	0.0025 Max.

Copper Nickel 95/5 Condenser Tube Mechanical & Physical Properties

Element	Cu-Ni 95/5
Density	0.323 lb/cu
Melting Point	1090 F
Tensile Strength	240 MPa
Yield Strength (0.2%Offset)	100 MPa
Elongation	30 %

Application

Aerospace

Cleaning Factories

Food Processing

Food Processing

Oil and Gas

Oil and Gas

Pharmaceutical

Pharmaceutical

Power Plant

Power Plant

Ship Building

Ship Building

Water Systems

Water Systems

Refinery

Refinery
