Super Duplex Pipe

For Enquiry

Shahil
Jain

Marketing Head
Make an Appoinment

Welded Pipes
Seamless Pipes

Specification

Standards ASTM, AISI, JIS, DIN, EN, SUS, GB
Types Welded, Seamless, ERW, Fabricated, CEW, CDW, CDS, DOM
Size range 8" NB to 24" NB
Production technique Decoiling, Punching, Bending, Welding,  Cutting, Moulding
Form Round, Hydraulic,  Coiled,  Square,  U Shape,  Rectangular,  Straight,  Honed Tubes,  Pan Cake Coils
Thickness Range SCH 10, SCH 160, SCH XXH, SCH XXS, SCH 5, SCH 40, SCH XS, SCH 80S, SCH 80
Custom Size/Thickness Available
End Treaded, Beveled End, Plain End
Surface Finish 8K,  1D,  No.3,  180G,  BA,  No.4,  500G,  No.1,  Mirror Polished,  320G,  HL,  No.8, 400G,  2B,  600G or 800G Mirror finish Tubing,  2D,  400G Satin/ Hairline or Custom Finish as per customer's specification.
Marking Standard
 Name of Manufacturer
Schedule
Pressure Class
Tube Size, etc
Test Certificates
 Third Party Inspection Report
Manufacturer Test Certificate
Raw Materials Certificate
100% Radiography Test Report
Laboratory Test Certificate from Govt. Approved Lab
EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)

Super Duplex S2507 Pipes Chemical Composition

  Grade C Si Mn P S Cr Mo Ni N Other
S32750 / S32760 2507 0.030 0.80 1.20 0.035 0.020 24.0/26.0 3.0/5.0 6.00/8.00 0.24/0.32 Cu:0.50



Mechanical Properties of Super Duplex S32750 Welded Tubes

UNS No Grade Proof Stress
0.2% (MPa)		 Tensile Strength
(MPa)		 Elongation
A5(%)		 Hardness Max
HB HRB
S32750 / S32760 2507 550 795 15 310 32*



S32750 Pipe Types Out diameter Wall thickness Length
NB Sizes (in stock) 1/8” ~ 8” SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 Upto 6 Meters
S32750 Seamless Pipe (Custom Sizes) 5.0mm ~ 203.2mm As per requirement Upto 6 Meters
S32750 Welded Pipe (in Stock + Custom Sizes) 5.0mm ~ 1219.2mm 1.0 ~ 15.0 mm Upto 6 Meters





Super Duplex DIN NR. 1.4410 Pipe Size

Wall Sizes ( O.D.)
.010 1/16" , 1/8" , 3/16"
.020 1/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8"
.012 1/8"
.016 1/8" , 3/16"
.028 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2"
.035 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.049 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
.065 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3"
.083 1/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3"
.095 1/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2"
.109 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"
.120 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3"
.125 3/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4"
.134 1"
.250 3"
.375 3 1/2"



Super Duplex S32760 Pipe Tolerances

Super Duplex S32750 Tube OD Super Duplex S32750 Tube Tolerance
4mm to 35mm +/- 0.08mm
35mm to 38mm +/- 0.15mm
38mm to 60mm +/- 0.20mm
60mm and above +/- 0.25mm



Super Duplex 2507 Pipe Equivalent Grades

Equivalent Grades for S32750 / S32760 Super Duplex Stainless Steel Pipe

STANDARD UNS WERKSTOFF NR.
Super Duplex S32750 S32750 1.4410
Super Duplex S32760 S32760 1.4410



Super Duplex UNS S32760 Tubes Pressure Rating

Pipe Size Pipe Schedule 100°F 200° 300° 400° 500° 600° 650° 700° 750°
1 40 3048 2629 2362 2171 2019 1924 1867 1824 1810
1 80 4213 3634 3265 3002 2791 2659 2580 2528 2501
1 160 6140 5296 4759 4375 4068 3876 3761 3684 3646
1.5 40 2257 1947 1750 1608 1496 1425 1383 1354 1340
1.5 80 3182 2744 2466 2267 2108 2009 1949 1909 1889
1.5 160 4619 3984 3580 3291 3060 2916 2829 2772 2743
2 40 1902 1640 1474 1355 1260 1201 1165 1141 1129
2 80 2747 2369 2129 1957 1820 1734 1682 1648 1631
2 160 4499 3880 3486 3205 2980 2840 2755 2699 2671
3 40 1806 1558 1400 1287 1196 1140 1106 1084 1072
3 80 2553 2202 1979 1819 1691 1612 1564 1532 1516
3 160 3840 3312 2976 2736 2544 2424 2352 2304 2280
4 40 1531 1321 1187 1091 1014 967 938 919 909
4 80 2213 1909 1715 1577 1466 1397 1355 1328 1314
4 160 3601 3106 2791 2566 2386 2273 2206 2161 2138
5 40 1342 1158 1040 956 889 847 822 805 797
5 80 1981 1709 1535 1411 1312 1250 1213 1189 1176
5 160 3414 2945 2646 2433 2262 2155 2091 2049 2027
6 40 1219 1052 945 869 808 770 747 732 724
6 80 1913 1650 1483 1363 1267 1208 1172 1148 1136
6 160 3289 2836 2549 2343 2179 2076 2014 1973 1953
8 40 1073 926 832 765 711 678 657 644 637
8 80 1692 1459 1311 1205 1121 1068 1036 1015 1005
8 160 3175 2738 2460 2262 2103 2004 1944 1905 1885
10 40 974 840 755 694 945 615 596 584 578
10 80 1609 1388 1247 1147 1066 1016 986 966 956
10 160 3147 2714 2439 2242 2085 1986 1927 1880 1868
